Motor Control Centers or likewise called MCC's, are an assembly of one enclosed section or more, that have a common power bus mostly comprising motor control units. They have been utilized ever since the 1950's by the automobile trade, in view of the fact that they made use of a large number of electric motors. These days, they are utilized in various industrial and commercial applications.
Motor control centers are a modern method in factory assembly for several motor starters. This particular machinery can consist of variable frequency drives, programmable controllers and metering. The MCC's are usually utilized in the electrical service entrance for a building. Motor control centers often are utilized for low voltage, 3-phase alternating current motors that range from 230 volts to 600 volts. Medium voltage motor control centers are designed for large motors that vary from 2300 volts to 15000 volts. These units use vacuum contractors for switching with separate compartments to be able to accomplish power control and switching.
Inside factory locations and area that have dusty or corrosive processing, the MCC could be installed in climate controlled separated locations. Typically the MCC will be positioned on the factory floor near the machinery it is controlling.
A MCC has one or more vertical metal cabinet sections with power bus and provisions for plug-in mounting of individual motor controllers. Smaller controllers can be unplugged from the cabinet in order to complete testing or maintenance, while very big controllers can be bolted in place. Every motor controller consists of a solid state motor controller or a contractor, overload relays so as to protect the motor, fuses or circuit breakers to provide short-circuit protection and a disconnecting switch so as to isolate the motor circuit. Separate connectors allow 3-phase power in order to enter the controller. The motor is wired to terminals located in the controller. Motor control centers provide wire ways for field control and power cables.
In a motor control center, every motor controller could be specified with a lot of various choices. Some of the options consist of: pilot lamps, separate control transformers, extra control terminal blocks, control switches, and various types of bi-metal and solid-state overload protection relays. They likewise have different classes of types of circuit breakers and power fuses.
There are lots of choices regarding delivery of MCC's to the customer. They could be delivered as an engineered assembly with interlocking wiring to a central control terminal panel board or programmable controller together with internal control. Conversely, they can be provided ready for the client to connect all field wiring.
Motor control centers typically sit on the floor and must have a fire-resistance rating. Fire stops can be necessary for cables which go through fire-rated floors and walls.
